Avalon mining machine complete set of accessories and connection methods

Avalon mining machine complete set of accessories list

1. The list of mining machine accessories is as follows. Table 1 is the list of accessories required for 1 mining machine; Table 2 is the list of accessories required for 10 mining machines; if there are more than 10 machines, the list of accessories for 10 machines is used as the basis, and so on:

Accessories Notes:

★ One mining machine includes one 5-pin cable, which is the default configuration;
★★ One AUC3 will be given for every five mining machines by default. This is the current discount.
★★★ Raspberry Pi and power supply are not directly produced by our company, so customers need to purchase them separately, or contact the corresponding sales to make arrangements. You need to bring your own card reader and network cable.

Accessories Description:

1. The 5-pin cable is used as the connection cable for the mining machine. The 5-pin cable is used to initially connect the AUC3 and the machine, and can also be used to connect the mining machines to each other.

2. AUC3 is a data converter that plays the role of data transmission. One AUC3 can support up to 5 mining machines;

3. Raspberry Pi is the controller, and the machine operation details can be viewed through the Raspberry Pi background. A Raspberry Pi III has 4 USB ports and can connect up to 4 AUC3s, which means it can support up to 20 mining machines. It is recommended to support 10 mining machines for stable operation.

The above accessories are universal for A7 series, A8 series and A9 series;

About Raspberry Pi: Different models of mining machines cannot be used on the same Raspberry Pi. You can update the Raspberry Pi memory card to the Raspberry Pi firmware of the corresponding mining machine model.

4. Mining machine power requirements:

a. A841 power supply is recommended to use a high-quality server power supply with an output capacity of more than 1500W and a conversion rate of more than 90%. The machine has 8 6-pin ports;

b. A851 power supply is recommended to use a high-quality server power supply with an output capacity of more than 1800W and a conversion rate of more than 93%. The machine has 8 6-pin ports;

c. A921 power supply is recommended to use a high-quality server power supply with an output capacity of more than 2200W and a conversion rate of more than 93%. The machine has 10 6-pin ports;

2. The following figure is a connection diagram for the A821 model. The connection methods of other Avalon mining machines are similar to this:
