APW3++ Power Supply Usage Introduction

1. Can bring mining machines
APW3++: 10 PCIE output interfaces, can support one S9 or T9, or one L3+;
APW3++ L3+ only: 18 PCIE output interfaces, can support two L3+ mining machines, or one S9 or T9;
The difference between the above two power supplies lies in the output interface, there is no other difference.
The above instructions are for use under 220V voltage. 110V can only support one L3+.
2. 220V voltage output parameters
DC voltage 12.15V; rated current 133A; rated power 1600W
3. 110V voltage output parameters
DC voltage 12.15V; rated current 100A; rated power 1200W
4. Power input interface
Pin-shaped interface, the same interface as desktop PC power supply
5. Remote operation of power on and off method: There is a resistor under the "-" and "NO" positions. Remove the resistors under these two positions, lead out two wires at these two positions, and connect them to the remotely controlled device. Now the power supply can be remotely turned on and off using the remotely controlled device.

7. The official website APW3 series power supply model is distinguished as shown below
